China Thrust Ball Bearings 2900 series,Thrust Ball Bearings 2900 series Manufacturer
Thrust Ball Bearing is designed only can bear axial loading,can transfer a large loading.It is mainly applied for the Automobile Steering Systems or Machine Tool Spindles. 2900 series.
Thrust Ball Bearings
2900 Series
| Bearing No. | Boundary Dimensions (mm) | Basic Load Rating | Wt. | |||
| d | D | T | Ca (KN) | Coa (KN) | (kg) | |
| 2900 | 10 | 26 | 12 | 9.95 | 17.10 | 0.033 |
| 2901 | 12 | 28 | 12 | 10.30 | 19.00 | 0.037 |
| 2902 | 15 | 31 | 12 | 11.20 | 24.80 | 0.041 |
| 2903 | 18 | 35 | 12 | 11.30 | 27.30 | 0.045 |
| 2904 | 20 | 37 | 12 | 11.60 | 37.70 | 0.055 |
| 2904 (1/2) | 22 | 42 | 14 | 14.90 | 50.40 | 0.084 |
| 2905 | 25 | 45 | 14 | 15.10 | 58.20 | 0.094 |
| 2906 | 30 | 50 | 14 | 15.80 | 78.20 | 0.108 |
| 2907 | 35 | 55 | 16 | 23.40 | 98.30 | 0.138 |
| 2908 | 40 | 60 | 16 | 24.50 | 105.00 | 0.154 |
| 2909 | 45 | 68 | 16 | 25.40 | 111.00 | 0.200 |
| 2910 | 50 | 74 | 18 | 30.00 | 159.00 | 0.257 |
| 2911 | 55 | 78 | 18 | 31.50 | 179.00 | 0.264 |
| 2912 | 60 | 82 | 18 | 31.50 | 189.00 | 0.270 |
| 2913 | 65 | 90 | 20 | 32.50 | 189.00 | 0.372 |
| 2914 | 70 | 95 | 20 | 34.00 | 209.00 | 0.396 |
| 2915 | 75 | 100 | 20 | 35.00 | 218.00 | 0.420 |
