China Thrust Ball Bearings 51100 series,Thrust Ball Bearings 51100 series Manufacturer
Thrust Ball Bearing is designed only can bear axial loading,can transfer a large loading.It is mainly applied for the Automobile Steering Systems or Machine Tool Spindles. 51100 series.
Thrust Ball Bearings
51100 Series
| Bearing No. | Boundary Dimensions (mm) | Basic Load Rating | Wt. | |||
| d | D | T | Ca (KN) | Coa (KN) | (kg) | |
| 51100 | 10 | 24 | 9 | 10.00 | 14.00 | 0.021 |
| 51101 | 12 | 26 | 9 | 10.30 | 15.40 | 0.023 |
| 51102 | 15 | 28 | 9 | 10.50 | 16.80 | 0.024 |
| 51103 | 17 | 30 | 9 | 10.80 | 18.20 | 0.026 |
| 51104 | 20 | 35 | 10 | 14.20 | 24.70 | 0.040 |
| 51105 | 25 | 42 | 11 | 19.60 | 37.20 | 0.060 |
| 51106 | 30 | 47 | 11 | 20.40 | 42.20 | 0.069 |
| 51107 | 35 | 52 | 12 | 20.40 | 44.70 | 0.085 |
| 51108 | 40 | 60 | 13 | 26.90 | 62.80 | 0.120 |
| 51109 | 45 | 65 | 14 | 27.80 | 69.10 | 0.150 |
| 51110 | 50 | 70 | 14 | 28.80 | 75.10 | 0.160 |
| 51111 | 55 | 78 | 16 | 34.80 | 93.10 | 0.240 |
| 51112 | 60 | 85 | 17 | 41.40 | 113.00 | 0.290 |
| 51113 | 65 | 90 | 18 | 41.70 | 117.00 | 0.324 |
| 51114 | 70 | 95 | 18 | 43.00 | 127.00 | 0.360 |
| 51115 | 75 | 100 | 19 | 42.30 | 127.00 | 0.392 |
| 51116 | 80 | 105 | 19 | 44.60 | 141.00 | 0.433 |
| 51117 | 85 | 110 | 19 | 45.90 | 150.00 | 0.460 |
| 51118 | 90 | 120 | 22 | 59.70 | 190.00 | 0.656 |
| 51120 | 100 | 135 | 25 | 85.00 | 268.00 | 1.000 |
| 51122 | 110 | 145 | 25 | 87.10 | 288.00 | 1.080 |
| 51124 | 120 | 155 | 25 | 89.00 | 308.00 | 1.110 |
| 51126 | 130 | 170 | 30 | 104.00 | 352.00 | 1.730 |
| 51128 | 140 | 180 | 31 | 107.00 | 377.00 | 1.900 |
| 51130 | 150 | 190 | 31 | 109.00 | 402.00 | 2.000 |
| 51132 | 160 | 200 | 31 | 112.00 | 425.00 | 2.100 |
